Cartridge Filtration

Single Fluid Industrial Filter Housing

Single Fluid Industrial Filter Housing

Model: TGDG

Brand: JHENTEN

Casting type, easy to replace, single round filter
Z JTGDG Single Fluid Industrial Filter Housing the top adopt integrated casting type structure , Using top entry top out design, with the adaptor, can be directly connected to the pipeline, the installation is extremely convenient.

Detail Description

ZJTGDG Single Fluid Industrial Filter have the integrated casting top adoptor structure , Using top entry top out design, with the adaptor, can be directly connected to the pipeline, the installation is extremely convenient.

The filter housing is sanitary grade, polishing precision Ra < 0.6μm, suitable for many kinds of filter requirements

JTGDG  Single Fluid Industrial Filter with very compact structure design , the top can be fixed in the pipeline.when you exchange the cartridges, just open the filter housing, the whole process without material liquid leakage.

Drain valve at the bottom.It's convenient for operator to discharge liquid.


Feature

The filter is top entry & top out structure , Can be directly connected to the pipeline
It's easy to change cartridge, and no liquid leakage
Drain valve at the bottom.It's convenient for operator to discharge liquid
Safety seal design


Application

Water Finish: all kinds of water filtration
Food & beverage: wine, mineral water, drinking water filtration
Chemical industry: all kinds of organic solvents, acid, alkali, filtration


Surface Finish

Treatment Type

base:cast

shell:Mechanical polishing, electrolytic polishing, sand blastingpickling

Polishing precision

Inner surface Ra≤0.4μm ,
Outside surface Ra≤0.6μm.


Operating Conditions

Max Operating pressure

0.6MPa

Max Operating Temp.

150℃


Material

Filter shell

304, 316L, SAF2507, carbon steel

Drain valve

304, 316L

O-ring

EPDM, PTFE, Viton, Silicone


Connection

Shell connection

quick-open, screwthread

In-outlet N1, N2

1”  screw thread

Pressure gauge N3 (optional)

1/4” screw thread

Drain valve N4, N5(Optional)

1/4” screw thread

Cartridge connection

DOE type


Structure

Dimension Parameters

1pc

10”

20”

30”

A:Total height

382

632

982

B:The distance from inlet to outlet

130

C:Diameter

Φ89

The above-mentioned data is the standard, it can customize according tocustomer's requirements.


SelectionTable


[Qty. of cartridge]

[Model of cartridge]

[Cartridges connection]

[Shell material]

[In-outlet Connection]

[O-ring]

JTGDG

1R

20

D

4

L

E


1R=1pcs

10=10” cartridge

D=DOE type

4= 304

L= thread

E=EPDM



20=20” cartridge


6= 316L


P=PTFE



30=30” cartridge




V=Viton



40=40” cartridge




S=Silicone
