Fermenter

Biological Fermentation Tank

Biological Fermentation Tank

Model: JTRSF

Brand: JHENTEN

Biological Fermentation Tank be designed, manufactured and inspected in accordance with the pressure vessel standard(GB150-2011) and the steel welded atmospheric pressure vessel standard(NB/T 47003.1-2009) , strictly meet to GMP certificate requirements.

Detail Description


Biological Fermentation Tank be designed, manufactured and inspected in accordance with the pressure vessel standard(GB150-2011) and the steel welded atmospheric pressure vessel standard(NB/T 47003.1-2009) , strictly meet to GMP certificate requirements.

Biological fermentation tank use vertical circular tanks, upper portion is standard elliptic or butterfly head, bottom is the standard or elliptic, butterfly head conical head, tank wall adopts circular arc transition, no dead corner, easy to clean;Can optional configure various forms of jacket, tanks and the head is equipped with the jacket and insulation layer, the top configuration of mechanical stirring .


Tank Optional Configuration

Biological Fermentation Tank Optional Configuration: sterile air filter, thermometer (digital display type or dial), PH meter, pressure gauge, steam sterilization port, sight glasses, sanitary manhole, in-outlet ,CIP universal rotating cleaning ball, liquid level meter and liquid level self-control system (bearing module, non-contact ultrasonic, static pressure transmitting device), etc.,or configured according to customers' requirements.


Application
? Suitable for medicine, biological products, dairy products, food, brewing, beverage, personal care products industries etc.


Feature
? There are 600L~20000L varietys of specifications, it can be designed, customized according to the customers' requirements.
? Jacket can put into steam (or hot water), jacket is divided into coil jacket,full jacket, dimple jacket; Jacketed outside covered with insulation layer, insulation material is rock wool (keep warm) or PU (keep cold).
? Connector use fast installation chuck(clamp), inner tank use SS304 or SS316L, the inner surface mirror polishing Ra≤0.28μm~0.6μm, outer surface can be polishing, wiredrawing ,sandblasting according to customer's requirement.

Design Parameter

Designpressure

0.02MPa~1.0MPa

Designtemperature

According tothe customers' requirements(0℃~160℃)


Material

Inner

304、316L

Insulation

Rockwool(keepwarm)
PU(keep cool)

Feet

304


Surface Finish

Finishtype

Mechanical polishing, electrolyticpolishing,
Sand blasting , pickling

Polishing precision

Inner surface Ra≤0.4μm
Outer surface Ra≤0.6μm


Connection

In-outlet

Tri-clamp,Flange


Coil jacket type Biological Fermentation Tank(斜葉槳式攪拌槳、conical bottom head)           Full jacket type Biological Fermentation Tank(斜葉槳式攪拌槳、elliptical bottom head)



Normal Model And MainTechnical Parameters

Parameters

Model

JTRSF—600

JTRSF—1000

JTRSF—2000

JTRSF—3000

JTRSF—4000

JTRSF—5000

Effectivevolume:L

600

1000

2000

3000

4000

5000

Barrel

Diameter:mm

Φ900

Φ1100

Φ1300

Φ1600

Φ1700

Φ1800

Height:mm

900

1000

1500

1500

1800

1800

Mixing

Motor power:kW

1.1

1.5

2.2

2.2

3

4

Mixing work RPM:r/min

60(斜葉槳式)(The design canbe adjusted according to customers’ usage)

JTRSF—6000

JTRSF—8000

JTRSF—10000

JTRSF—12000

JTRSF—15000

JTRSF—20000


6000

8000

10000

12000

15000

20000


Φ1900

Φ2000

Φ2200

Φ2400

Φ2600

Φ2800


2000

2200

2400

2500

2700

3000


4

5.5

7.5

7.5

11

11


60(斜葉槳式)(The design canbe adjusted according to customers’ usage)


Theabove-mentioned data is the standard ,for reference only. it can customizeaccording to customer's requirements.
